Deployment Templates of AWS Services via AWS CDK (in TypeScript)

import { Stack, aws_wafv2 } from 'aws-cdk-lib';

class TemplateStack extends Stack {
    constructor(scope: App, id: string, props: StackProps) {
        super(scope, id, props);

        new aws_wafv2.CfnWebACL(this, 'apiWebAcl', {
        defaultAction: {
            block: {},
        },
       /* Specifies whether this is for an Amazon CloudFront distribution or for a regional application.
        * A regional application can be an Application Load Balancer (ALB), an Amazon API Gateway REST API,
        * an AWS AppSync GraphQL API, an Amazon Cognito user pool, or an AWS App Runner service. Valid Values are `CLOUDFRONT` and `REGIONAL`
        * @link http://docs.aws.amazon.com/AWSCloudFormation/latest/UserGuide/aws-resource-wafv2-webacl.html#cfn-wafv2-webacl-scope
        */
        scope: 'CLOUDFRONT',
        visibilityConfig: {
            cloudWatchMetricsEnabled: true,
            metricName: 'MetricForWebACLCDK',
            sampledRequestsEnabled: true,
        },
        name: 'ApiWebAclRules', // optional
        rules: aclRules, // optional, sample shown below in Sample ACL Rules
        });
    }
}

import { aws_wafv2 } from 'aws-cdk-lib';

export const aclRules: aws_wafv2.CfnWebACLProps['rules'] = [
  // AWS default rules
  // Details in <https://docs.aws.amazon.com/waf/latest/developerguide/aws-managed-rule-groups-baseline.html>
  {
    name: 'CRSRule',
    priority: 0,
    statement: {
      managedRuleGroupStatement: {
        name: 'AWSManagedRulesCommonRuleSet',
        vendorName: 'AWS',
      },
    },
    visibilityConfig: {
      cloudWatchMetricsEnabled: true,
      metricName: 'MetricForWebACLCDK-CRS',
      sampledRequestsEnabled: true,
    },
    overrideAction: {
      none: {},
    },
  },
  {
    name: 'KnownBadInputsRule',
    priority: 2,
    statement: {
      managedRuleGroupStatement: {
        name: 'AWSManagedRulesKnownBadInputsRuleSet',
        vendorName: 'AWS',
      },
    },
    visibilityConfig: {
      cloudWatchMetricsEnabled: true,
      metricName: 'MetricForWebACLCDK-KnownBadInputs',
      sampledRequestsEnabled: true,
    },
    overrideAction: {
      none: {},
    },
  },
  // Customized Rules
  // Block requests from IP which exceeded 50k requests per 5 minutes
  {
    name: 'RateLimitByIP',
    priority: 4,
    statement: {
      rateBasedStatement: {
        limit: 50000,
        aggregateKeyType: 'IP',
      },
    },
    action: {
      block: {},
    },
    visibilityConfig: {
      cloudWatchMetricsEnabled: true,
      metricName: 'MetricForWebACLCDK-RateLimit',
      sampledRequestsEnabled: true,
    },
  },
  // Only allow requests with specific prefix
  {
    name: 'ByteMatchForHeaders',
    priority: 6,
    statement: {
      byteMatchStatement: {
        fieldToMatch: {
          headers: {
            matchPattern: { includedHeaders: ['Authorization'] },
            matchScope: 'VALUE',
            oversizeHandling: 'CONTINUE',
          },
        },
        searchString: 'TARGET_PREFIX_STRING',
        positionalConstraint: 'STARTS_WITH',
        textTransformations: [{ priority: 0, type: 'COMPRESS_WHITE_SPACE' }],
      },
    },
    action: {
      allow: {},
    },
    visibilityConfig: {
      cloudWatchMetricsEnabled: true,
      metricName: 'MetricForWebACLCDK-geoMatchForLabels',
      sampledRequestsEnabled: true,
    },
  },
];

import { App, Stack, aws_cloudfront, aws_lambda as lambda } from 'aws-cdk-lib';
import { HttpOrigin } from 'aws-cdk-lib/aws-cloudfront-origins';
import { HttpApi } from '@aws-cdk/aws-apigatewayv2-alpha';
import { join } from 'path';

class TemplateStack extends Stack {
    constructor(scope: App, id: string, props: StackProps) {
        super(scope, id, props);

       /* Lambda@Edge function to remove the service prefix from the path
        * before forwarding the request to the origin API Gateway
        *
        * ONLY solution to customize the request after received by the CloudFront distribution
        * and before forwarding the request to the origin API Gateway
        *
        * Comparision: Base path mapping vs. CloudFront Distribution
        * 1) Base path mapping:
        * Ex. https://custom-api-domain/some_route/v1/some_subroute -> (mapping) https://custom-api-domain/some_subroute
        *
        * 2) CloudFront Distribution:
        * Ex. https://custom-api-domain/some_route/v1/some_subroute -> (forward to origin API Gateway) https://CLOUD_FRONT_DISTRIBUTION_DOMAIN/some_subroute
        */
        const originRequestHandlerFn = new cloudfront.experimental.EdgeFunction(
            this,
            'originRequestHandler',
            {
                runtime: lambda.Runtime.NODEJS_16_X,
                handler: 'cloudfrontRequestHandler.handler', // format: [FILENAME].[FUNCTION_NAME], which has to be in JavaScript, not TypeSCript
                code: lambda.Code.fromAsset(join(__dirname, 'LAMBDA_EDGE_RELATIVE_PATH')),
            }
        );

        /* default behavior options for CloudFront Distribution */
        const addBeheviorDefaultOptions: aws_cloudfront.AddBehaviorOptions = {
            allowedMethods: aws_cloudfront.AllowedMethods.ALLOW_ALL,
            viewerProtocolPolicy: aws_cloudfront.ViewerProtocolPolicy.REDIRECT_TO_HTTPS,

            // recommended config for api gateway by AWS
            originRequestPolicy: aws_cloudfront.OriginRequestPolicy.ALL_VIEWER_EXCEPT_HOST_HEADER,
            cachePolicy: aws_cloudfront.CachePolicy.CACHING_DISABLED,
        };

        /* CloudFront Distribution for API Gateways */
        this.cloudfrontDistribution = new aws_cloudfront.Distribution(this, 'GlobalApiDistribution', {
        comment: 'Global API Distribution',
        defaultBehavior: {
            ...addBeheviorDefaultOptions,
            origin: new HttpOrigin(`execute-api.${this.region}.amazonaws.com`),
        },
        domainNames: domainName ? [domainName] : [], // custom api domain name
        certificate: SSLCertificate, // certifiacte for SSL
        sslSupportMethod: aws_cloudfront.SSLMethod.SNI,
        webAclId: SOME_WAF_ACL.attrArn, // optional
        });

        /* Sample API */
        const sampleApi: HttpApi = props.sampleApi;

        const sampleApiOrigin = new HttpOrigin(
            `${sampleApi.httpApiId}.execute-api.${this.region}.amazonaws.com`
        );

        this.cloudfrontDistribution.addBehavior('/sampleRoute/v1*', sampleApiOrigin, {
            ...this.addBeheviorDefaultOptions,
            edgeLambdas: [
            {
                eventType: cloudfront.LambdaEdgeEventType.ORIGIN_REQUEST,
                functionVersion: originRequestHandlerFn.currentVersion,
                includeBody: false,
            },
            ],
        });
    }
}

exports.handler = async function (event) {
  const request = event.Records[0].cf.request;

  /* Remove the API Gateway prefix from the request path before forwarding the request to the origin API Gateway
   * Ex. (original uri) /sample_route/v1/sample_subroute -> (after replacement) /sample_subroute
   */
  request.uri = request.uri.replace('/sample_route/v1/', '/');

  console.log('EVENT: \n' + JSON.stringify(event, null, 2));
  return request;
};

import { aws_s3 as S3, aws_s3_deployment as S3_Deployment } from 'aws-cdk-lib';
import { Construct } from 'constructs';
import path from 'path';
import * as fs from 'fs';

class SampleCustomConstruct extends Constuct {
    public sampleContentInS3Bucket = [];
    private _s3Bucket: S3.Bucket;
    private _s3Key: string;
    private s3KeyPrefix: string;
    private outputDir: string;

    // CONSTRUCTORS
    constructor(
        scope: Construct,
        id: string,
        props: { s3Bucket: S3.Bucket; s3KeyPrefix: string; outputDir: string }
    ) {
        super(scope, id);
        this._s3Bucket = props.s3Bucket;
        this._s3Key = `${props.s3KeyPrefix}/sampleContentInS3Bucket.json`;
        this.s3KeyPrefix = props.s3KeyPrefix;
        this.outputDir = props.outputDir;
    }

    // ACCESSORS
    public get s3Bucket(): S3.Bucket {
        return this._s3Bucket;
    }
    public get s3Key(): string {
        return this._s3Key;
    }

    // MODIFERS
    public addContent(sampleContentInS3Bucket: any) {
        this.sampleContentInS3Bucket.push(sampleContentInS3Bucket);
    }

    public deployBucket() {
        fs.mkdirSync(this.outputDir, { recursive: true });
        fs.writeFileSync(path.join(this.outputDir, 'sample.json'), JSON.stringify(this.sampleContentInS3Bucket));

        new S3_Deployment.BucketDeployment(this, 'SampleBucketDeployment', {
            sources: [S3_Deployment.Source.asset(this.outputDir)], // The local dir/zip-file to be uploaded to AWS S3 Bucket
            destinationBucket: this._s3Bucket, // The S3 Bucket in AWS
            destinationKeyPrefix: this.s3KeyPrefix, // The specific path (file/dir) inside S3 Bucket
        });
    }
}

const sampleBucket = new aws_s3.Bucket(this, 'SampleBucket', {
    /* The S3 Bucket will automatically get destroyed when stack destroyed */
    removalPolicy: RemovalPolicy.DESTROY,
    autoDeleteObjects: true,
});

import jwksClient from 'jwks-rsa';
import jwt from 'jsonwebtoken';
import { APIGatewayAuthorizerResult } from 'aws-lambda/trigger/api-gateway-authorizer';
import S3Client from 'SOME_WHERE';

export type ApiPermission = {
  arn?: string;
  stage?: string;
  httpMethod: string;
  path: string;
  scopes: string[];
};

let apiPermissions: ApiPermission[] | undefined;

const client = jwksClient({
  cache: true,
  rateLimit: true,
  jwksRequestsPerMinute: 10, // Default value
  jwksUri: process.env.JWKS_URI ?? 'https://sample_jwks_uri/.well-known/jwks.json',
});

const defaultDenyAllPolicy = {
  principalId: 'user',
  policyDocument: {
    Version: '2012-10-17',
    Statement: [
      {
        Action: 'execute-api:Invoke',
        Effect: 'Deny',
        Resource: '*',
      },
    ],
  },
};

function getToken(params: any) {
  if (!params.type || params.type !== 'REQUEST') {
    throw new Error('Expected "event.type" parameter to have value "TOKEN"');
  }

  const tokenString = params.authorizationToken;
  if (!tokenString) {
    throw new Error('Expected "event.authorizationToken" parameter to be set');
  }

  const match = tokenString.match(/^Bearer (.*)$/);
  if (!match || match.length < 2) {
    throw new Error(`Invalid Authorization token - ${tokenString} does not match "Bearer .*"`);
  }
  return match[1];
}

async function generatePolicy(
  scopeClaims: string[],
  httpMethod: string,
  path: string,
  methodArn: string,
  principalId: string,
): Promise<APIGatewayAuthorizerResult> {
  // Retrieve API permissions from S3 if not already retrieved
  if (!apiPermissions && process.env.S3_BUCKET_NAME && process.env.S3_KEY) {
    console.log(' == RETRIEVING S3 BUCKET == ', process.env.S3_BUCKET_NAME, process.env.S3_KEY);
    apiPermissions = JSON.parse(await S3Client.get(process.env.S3_BUCKET_NAME, process.env.S3_KEY));
    console.log('== RETRIEVED API PERMISSIONS ==\n', apiPermissions);
  }

  // If no API permissions are defined, return default deny all policy
  if (apiPermissions === undefined) {
    return defaultDenyAllPolicy;
  }

  const policyStatements = [];

  for (let i = 0; i < apiPermissions.length; i++) {
    let isPermissionMatched = true;

    // Check scopes
    for (let j = 0; j < apiPermissions[i].scopes.length; j++) {
      if (scopeClaims.includes(apiPermissions[i].scopes[j]) === false) {
        isPermissionMatched = false;
        break;
      }
    }

    // Check route & method
    if (httpMethod !== apiPermissions[i].httpMethod || path !== apiPermissions[i].path) {
      isPermissionMatched = false;
    }

    if (!isPermissionMatched) continue;
    policyStatements.push({ Action: 'execute-api:Invoke', Effect: 'Allow', Resource: methodArn });
  }

  // Check if no policy statements are generated, if so, create default deny all policy statement
  if (policyStatements.length === 0) {
    return defaultDenyAllPolicy;
  } else {
    return {
      principalId,
      policyDocument: {
        Version: '2012-10-17',
        Statement: policyStatements,
      },
      context: {},
    };
  }
}

export const handler = async (
  params: AWSLambda.APIGatewayRequestAuthorizerEvent
): Promise<APIGatewayAuthorizerResult> => {
  console.log('== params ==\n', params);

  const xOriginVerify = params.headers ? params.headers['X-Origin-Verify'] : null;
  if (xOriginVerify !== process.env.X_ORIGIN_VERIFY) {
    throw new Error('invalid origin');
  }

  const token = getToken(params);
  console.log('== token ==\n', token);

  const decoded: any = jwt.decode(token, { complete: true });
  if (!decoded || !decoded.header || !decoded.header.kid) {
    throw new Error('invalid token');
  }
  console.log('== decoded ==\n', decoded);

  try {
    console.log('JWKS_URI', process.env.JWKS_URI);

    const key = await client.getSigningKey(decoded.header.kid);
    console.log('== key ==\n', key);

    const decodedToken = jwt.verify(token, key.getPublicKey(), {
      algorithms: ['RS256'],
      audience: process.env.AUTH0_AUDIENCE,
      issuer: process.env.AUTH0_ISSUER,
    });
    console.log('== decodedToken ==\n', decodedToken);

    if (typeof decodedToken === 'string') {
      console.log('ERROR: decodedToken is a string');
      return defaultDenyAllPolicy;
    }
    const scopeClaims = decodedToken.scope.split(' ');

    // Generate IAM Policy
    const iamPolicy = await generatePolicy(
      scopeClaims,
      params.requestContext.httpMethod,
      params.requestContext.resourcePath,
      params.methodArn,
      decodedToken.sub as string
    );
    console.log('== policy ==\n', iamPolicy);
    console.log('== policy statements ==\n', iamPolicy.policyDocument.Statement);

    return iamPolicy;
  } catch (error) {
    console.error(error);
    return defaultDenyAllPolicy;
  }
};

import { S3Client as S3, PutObjectCommand, GetObjectCommand } from '@aws-sdk/client-s3';
import { getSignedUrl } from '@aws-sdk/s3-request-presigner';

const DEFAULT_EXPIRES_TWO_WEEK = 60 * 60 * 24 * 7;

export default class S3Client {
  private static s3Client = new S3({
    region: 'us-east-1',
  });

  /**
   * @param dataBody input data as an object format
   * @returns return the pre-signed URL which would provide the permission for users to access the S3 data
   */
  public static async upload(
    bucketName: string,
    s3Key: string,
    objectData: string,
    expires: number = DEFAULT_EXPIRES_TWO_WEEK
  ): Promise<string> {
    const s3Params = new PutObjectCommand({
      Bucket: bucketName,
      Key: s3Key,
      Body: objectData,
    });

    await this.s3Client.send(s3Params);

    const urlParams = new GetObjectCommand({
      Bucket: bucketName,
      Key: s3Key,
    });

    // It's encrypted and whoever gets the url will get the full access of its own bucket data.
    return await getSignedUrl(this.s3Client, urlParams, { expiresIn: expires });
  }

  public static async get(bucketName: string, s3Key: string): Promise<string> {
    const s3Params = new GetObjectCommand({
      Bucket: bucketName,
      Key: s3Key,
    });

    try {
      const response = await this.s3Client.send(s3Params);
      const str = await response.Body?.transformToString();
      return str ?? '';
    } catch (error) {
      console.error(error);
      return 'Failed to get data from S3 Bucket';
    }
  }
}

import {
  HttpLambdaAuthorizer,
  HttpLambdaResponseType,
} from '@aws-cdk/aws-apigatewayv2-authorizers-alpha';
import {
  NodejsFunction as AWSNodeJsFunction,
  NodejsFunctionProps as AWSNodejsFunctionProps,
} from 'aws-cdk-lib/aws-lambda-nodejs';

// Init Lambda Authorizer
const lambdaAuthorizerFn = new AWSNodeJsFunction(this, 'LambdaAuthorizerFn', {
    stage: 'SAMPLE_STAGE',
    entry: join(__dirname, 'SAMPLE_PATH'),
    handler: 'SAMPLE_MAIN_FUNCTION_NAME',
    environment: {
        JWKS_URI: `${jwtIssuer}.well-known/jwks.json`,
        AUTH0_ISSUER: 'SAMPLE_JWT_Issuer',
        AUTH0_AUDIENCE: 'SAMPLE_JWT_Audience',
        S3_BUCKET_NAME: 'SAMPLE_S3_BUCKET_NAME',
        S3_KEY: 'SAMPLE_S3_KEY',
        X_ORIGIN_VERIFY: 'SAMPLE_X_ORIGIN_VERIFY',
    },
    timeout: Duration.seconds(5),
    memorySize: 1024,
});

// Allow lambda authorizer to retrieve all api permissions
sampleS3Bucket.grantRead(lambdaAuthorizerFn, 'SAMPLE_FOLDER_PATH' + '/*');

const lambdaAuthorizer = new HttpLambdaAuthorizer('LambdaAuthorizer', lambdaAuthorizerFn, {
    authorizerName: 'LambdaAuthorizer',
    identitySource: ['$request.header.Authorization'],
    resultsCacheTtl: Duration.seconds(0),
    responseTypes: [HttpLambdaResponseType.IAM],
});

import { HttpApi, HttpMethod, AddRoutesOptions } from '@aws-cdk/aws-apigatewayv2-alpha';

const sampleApi: HttpApi; // Need to assign some HttpApi (ApiGatewayV2)
const method = sampleApi.addRoutes({
    ...addRoutesOptions,
    /* AWS doesnt support `authorizationScopes` field when using lambda authorizer */
    authorizationScopes: undefined  });

// add scope & route/path info into S3 Bucket
const sampleCustomConstruct: SampleCustomConstruct // Need to assign some SampleCustomConstruct
sampleCustomConstruct.addPermission({
    httpMethod: addRoutesOptions.methods ? addRoutesOptions.methods[0] : HttpMethod.ANY,
    path: addRoutesOptions.path,
    scopes: addRoutesOptions.authorizationScopes?.map((scope) => scope.trim()) || [],
});
